When a job calls for more height than a yard forklift but still demands compact maneuverability on busy construction or industrial sites, a mid-range telehandler like the HAMAC HT3510 becomes the practical choice. With a maximum lifting height of 10.6 m and a rated capacity of 3500 kg, HT3510 is designed to place pallets and materials several floors up while keeping overall dimensions and weight manageable for mixed-use environments.
HT3510 sits between smaller 7 m machines and the tallest 13–18 m telehandlers, targeting low to mid-rise building construction, industrial plant maintenance and general material handling in yards where reach matters but extreme height is not required. It works well as a primary telehandler for medium contractors or as a flexible support unit in larger fleets that also operate cranes or higher-reach machines.
The machine is particularly suited to tasks such as delivering pallets of block or brick to third or fourth floor slab edges, placing roofing materials, and feeding work platforms with tools and consumables. In industrial settings, HT3510 can lift components, maintenance parts and equipment to mezzanines, service platforms and pipe racks that a standard forklift cannot safely reach.
HT3510 offers a maximum capacity of 3500 kg, a maximum lifting height of 10.6 m and a maximum outreach of 5.7 m, giving it a solid working envelope for mid-height tasks. At full height and outreach, operators should always refer to the load chart to confirm the permissible load for safe operation.
The telehandler is powered by a Yuchai diesel engine (model YCD4M22T-105) rated at 103 hp (77.3 kW), with 4 cylinders and a displacement of 4400 cm³, delivering up to 400 Nm of torque at 1400 rpm. This powertrain is paired with a torque converter transmission that provides 4 forward and 4 reverse gears and a maximum travel speed of 35 km/h, enabling efficient travel around larger sites and between work zones.
For its reach, HT3510 maintains compact overall dimensions: the length to the carriage is 5.8 m, overall width is 2.2 m and overall height is 2.55 m, with a wheelbase of 3.15 m. Ground clearance is 0.35 m, helping the machine traverse uneven, semi-rough ground commonly found on construction and industrial sites.
Unladen weight with forks is 9500 kg, giving the chassis the mass it needs to support the 3.5 ton rating at appropriate boom positions. Standard pneumatic 16/70‑20 tires and an external turning radius of 4.25 m support stable handling while still allowing the operator to maneuver in confined areas such as internal yards or around structures.
The HT3510 uses a gear-type hydraulic pump with a flow of 120 L/min, feeding the boom and attachment functions. Typical cycle times are 10 seconds for lifting, 7 seconds for lowering, about 12 seconds for extension and 8.6 seconds for retraction, with crowd and dump movements taking approximately 4.8 and 3.4 seconds respectively.
These cycle times translate into productive material handling on site, especially when the machine is repeatedly loading and unloading at the same height and outreach. A properly trained operator can sequence driving, boom positioning and fork movements to minimize idle time, making the most of the telehandler during peak activity periods.
HT3510 is equipped with an automatic air-cut parking brake and immersed multi-disc service brakes acting on both front and rear axles, designed to deliver reliable stopping performance in dusty and demanding conditions. Steering and drive are configured 2-wheel front and 2-wheel rear, providing predictable handling and traction suitable for construction and industrial ground conditions.
The cab meets FOPS level 2 requirements, offering the operator overhead protection against falling objects in line with typical telehandler safety expectations. Inside the cab, controls and visibility are designed to support flexible operation, allowing the driver to position loads accurately at height while maintaining awareness of surrounding personnel and obstacles.
The machine uses National II-compliant diesel fuel with a maximum sulfur content of 5000 ppm, and tank capacities include 195 L for fuel, 170 L for hydraulic oil and 5.5 L for engine oil. These capacities are sized to support a full shift of heavy work in most cases, reducing the need for frequent refueling or topping up during busy days.
Routine maintenance focuses on engine servicing, hydraulic oil and filter changes, brake system checks and daily inspection of tires, forks and boom components. Fleet owners who operate multiple HAMAC machines can benefit from component and parts commonality across the range, which simplifies spare parts stocking and technician training.
Noise at the driving position is rated at 82 dB, while noise to the environment is 105 dB, figures that are typical for telehandlers in this class and should be considered in noise management plans on sensitive sites. Vibration on hands and arms is listed at 2.50 m/s², meaning operators should follow recommended exposure guidelines and ensure proper training and work-rest cycles for long shifts.
Providing the operator with appropriate hearing and vibration protection where required, and ensuring the seat, controls and mirrors are correctly adjusted, will help maintain comfort and reduce fatigue, which in turn supports safer and more precise telehandler operation throughout the day.
On building sites, HT3510 is highly effective for delivering pallets of bricks, blocks, cement, plasterboard and roofing materials to upper floors or roof levels within its 10.6 m height range. It can also handle formwork components, rebar bundles and general construction supplies, supporting concrete, masonry and finishing trades.
In industrial plants, the machine is used to lift spare parts, pumps, motors and fabrication materials to platforms and service areas, as well as to support shutdown and turnaround activities where quick, controlled lifting is required. Material yards and distribution centers can use HT3510 to stack heavy goods at moderate heights, load trucks and reorganize stock where access and headroom allow.
| Model | Max lifting height | Rated load | Typical use |
|---|---|---|---|
| HT3007 | 7.0 m | 3000 kg | Light construction, yard work |
| HT3510 | 10.6 m | 3500 kg | Mid-rise construction, industrial sites |
| HT4014 | 13.8 m | 4000 kg | Taller buildings, extended outreach |
| HT4018 | 17.6 m | 4000 kg | High-rise and long reach applications |
For buyers, this means HT3510 is a good choice when you need more height and capacity than smaller 7 m machines provide, but do not require the larger size and cost of 14 m or 18 m telehandlers. It can serve as a versatile all-rounder on many projects, especially where site access is mixed and both indoor and outdoor work areas are involved.
Is 3500 kg capacity enough? For most palletized construction materials, packaged products and typical industrial loads, 3.5 tons is sufficient when used within the limits of the load chart; if your work involves heavier steel fabrications, large machinery or oversize components at reach, a higher-capacity model may be more appropriate.
Does 10.6 m reach cover your projects? This height can typically reach third or fourth floor levels depending on storey height and working angles, which is adequate for many commercial and residential buildings; projects with regular work above this level may justify moving to a 13.8 m or 17.6 m machine.
Do your sites allow for a 9.5-ton machine? With an unladen weight of 9500 kg and 2.2 m width, HT3510 is compact for its class but still requires suitable ground bearing capacity, access routes and turning space; checking site constraints early helps ensure smooth deployment and safe operation.
HAMAC HT3510 is best suited to contractors and industrial operators who need a balance between height, capacity and maneuverability, with enough reach for mid-rise work and enough strength to handle 3.5 ton loads across a useful working envelope. If your workload is dominated by deliveries up to a few floors and varied material handling tasks, this model can often cover the majority of telehandler needs on site.
Before making a final decision, it is recommended to map your typical loads and working heights against the HT3510 load chart, review any future project
